Wilcox RUGGEDIZED AIMING/ILLUMINATION DEVICE - ENHANCED - HIGH POWER
The Wilcox RAID Xe™ Rugged Aiming and Illumination Device is a high-power aiming module built for MIL-LE Operators carrying tactical rifles in dynamic, low-light environments. It features a co-aligned optical bench with VIS, NIR, and VCSEL illumination, maintaining one zero across all emitters under recoil. The adjustable IR illuminator provides rapid transition from tight PID to wide flood. Intuitive controls and remote capability keep operators’ heads up, enabling fast, decisive engagements.
FEATURES AND BENEFITS
- One (1) optical bench houses either red or green VIS laser, NIR laser, and adjustable NIR VCSEL illuminator
- Adjustable NIR VCSEL illuminator and wide angle fixed NIR VCSEL room illuminator project precise, speckle-free beams for extreme clarity and optimal combat identification
- Fixed NIR room illuminator provides 40º flood capability
- Optical bench is aligned to the weapon by one (1) windage and one (1) elevation adjustment
- Powered by one (1) CR123 battery providing approximately eight (8) hours of product usage at max settings
- Mounts to any 1913 Picatinny rail secured by two (2) Thumbnuts
- Multi-function keypads provide flexibility in programing custom options
- Five (5) selectable pulse modes on VIS/NIR laser settings
- On-the-fly laser brightness adjustment
- Security tethered loop tie down
- Keypad Port accepts Wilcox line of ERGOCTO® Xe Keypads and ERGOCTO Xe Control Grips (optional)
- ERGOCTO Xe Keypads provide three (3) user-defined functions regardless of switch position
Resources
RAID Xe Technical Datasheet
RAID Xe Quick Reference Video
RAID Xe Training Video
RAID Xe Product Brief
