Wilcox RAPTAR Xe
The Wilcox RAPTAR Xe™ Rapid Targeting and Ranging Module is a high-power advanced fire-control system for precision shooters operating at extended distances. It integrates a laser rangefinder, onboard ballistic solver, and full mission spectrum lasers into a single co-aligned optical bench, maintaining zero across the system. Real-time environmental inputs generate instant firing solutions while VCSEL illumination supports PID in low light conditions, keeping Operators on glass and on target.
FEATURES AND BENEFITS
- Single optical bench houses the red VIS laser, NIR laser, variable NIR Illuminator, and LRF
- NIR VCSEL Illuminator projects precise, speckle-free beams for extreme clarity and optimal combat identification
- Aligns to the weapon using one (1) windage and one (1) elevation adjustment
- Powered by one (1) CR123 battery
- Mounts to any 1913 Picatinny rail using two (2) Thumbnuts
- Multi-function remote Keypads provide flexibility in programing custom options
- Auto display brightness
- Illuminator spool adjusts beam divergence from 17-105 mrad (0.97°-6.01°)
- On-board ballistic computer measures temperature, pressure, humidity, inclination, cant, and heading; Wind speed and direction may be entered manually or via Bluetooth to calculate the ballistics solution
- Bluetooth interface provides key information on mobile devices and connectivity to auxiliary devices
- Large OLED Display outputs ballistics solution in MRAD, MOA, and Inches
- Programmable database stores up to 30 rifle and ammo profiles
- External Connector accepts Wilcox line of ERGOCTO® Xe Keypads
- Five (5) selectable pulse modes on VIS/NIR laser settings
- Security tethered loop tie down
Resources
RAPTAR Xe Technical Datasheet
RAPTAR Xe Demonstration Video
RAPTAR Xe Quick Reference Video
RAPTAR Xe Product Brief
RAPTAR Xe Operator's Manual
